CD600 Plus Multi-Loop Digital Controller Training
TC-120
The CD600 Plus is a powerful stand-alone single station capable of controlling simultaneously up to 4 loops, up to 8 PID's and more than 120 advanced controls function blocks.
This training module is a combination of product theoretical information and hands-on exercises covering product operation, configuration and maintenance procedures.
The participant will be able to
- Understand CD600 Plus features and general applications
- Operate the CD600 Plus frontal panel and rear terminal block
- Select, configure and apply the available product function blocks
- Apply CD600 Plus TagList and OPC standard for system supervision
- Calibrate the CD600 Plus digital controller analog inputs and outputs
Topics
- CD600 Plus functional description
- Frontal panel and rear terminal blocks description
- CD600 function blocks library
- Analog & discrete I/O
- Visualization and local/remote keys
- A/M station and PID control
- Alarm, arithmetic operations, analog integration, etc
- CONF600 - CD600 Plus software configuration tool
- CD600 Plus applications
- Supervision aspects - CD600 Plus OPC Server and TagList application
- CD600 Plus analog I/O calibration procedures
- Product installation aspects
Pre-requisite
Knowledge of industrial automation and computers (Windows environment)
Program length
24 hours (3 working days)
