HART + 4-20mA Density and Concentration Transmitter Training
TC-103
The DT301 concentration/density transmitter has a pioneer technology which consists of a capacitive type differential pressure transmitter coupled to a pair of pressure repeaters immersed in the process.
Applications: Industrial and sanitary service, requiring accurate density and liquid interface determination. Sugar and Alcohol, Dairy Products, Food, Beverage, Chemical, Mining Slurries, Pulp & Paper Mills, Petrochemical and others.
The HART + 4-20mA Density Transmitter 300 Series training course is a combination of theoretical information and hands-on exercises covering product installation, operation, configuration, maintenance procedures and general application for concentration and density measurement.
The participant will be able to
- Use the PALM and DEVCODROID configuration software tools
- Configure all functions available on the device´s programming tree
- Understand how the different types of density/concentration devices work
- Understand how the interface of two liquids measurement is done
- Apply the device maintenance procedures using PALM and DEVCODROID software
Topics
- Density and concentration measurement using Smar products
- DT301 Density & concentrator functional description
- Device operation and programming tree applications
- Product Installation and applications
- HART + 4-20mA communication
- Transmitter and controller mode
- HI331 e PC Windows and HI321 interfaces
- Hands-on using PALM and DEVCODROID Configuration Software
- Local adjustment using the magnetic screwdriver SD1, PALM and DEVCODROID software
- FDT/DTM for Smar density & concentration transmitter
- Product ordering code
Pre-requisite
Knowledge of industrial automation and computers (Windows environment)
Program length
8 hours (1 working day)
8 hours (1 working day)
