LC700 Programmable Controller Training
TC-121
The LC700 is the seventh generation of controllers from Smar, and our experience from a wide range of industries is reflected in this device. Since its introduction it has been successfully field proven in many simple and complex installations in a wide range of industries, e.g., petrochemical, water treatment, pharmaceutical, food industry, sugar mill, power plants, pollution control among others.
This training module covers the LC700 general functions, programming tool and product general maintenance procedures as well.
The participant will be able to
- Understand LC700 features and general applications
- Know LC700 hardware structure and the I/O modules available
- Apply the LC700 software configuration Tool
- Program CONF700 LADDER Logic with function blocks support
- Configure LC700 programmable controller for redundant applications
- Configure LC700 using MODBUS RTU & TCP/IP communication
- Apply LC700 TagList and OPC standard for system supervision
- Understand the LC700 maintenance tools and procedures
Topics
- LC700 functional description
- LC700 I/O modules features and applications
- CONF 700 - LADDER configuration tool Logic tool and function blocks configuration
- LC700 in remote and redundant applications
- MB-700 - master/slave, serial, MODBUS, concentrator and TCP/IP processor
- ENET-710 – MODBUS RTU & TCP/IP processor
- LC700 TagList and OPC standard for system supervision
- LC700 general maintenance procedures and tools
- Product installation aspects
Pre-requisite
Knowledge of industrial automation and computers (Windows environment)
Knowledge of industrial automation and computers (Windows environment)
Program length
24 hours (3 working days)
