Training in SYSTEM302 Controller HSE DF100 WirelessHART

This training module introduces Smar SYSTEM302 architecture to Wireless HART applications, focusing general configuration, network communication environment, operational system and tools.

The participant will able to

• Know the benefits of WirelessHART technology
• Know the SYSTEM302 components applied to Wireless HART applications
• Design, setup and configure Wireless HART networks
• Configure I/O Mapping via MODBUS
• Understand OPC communication aspects – supervision system
• Apply system operational tools and settings

Topics

• WirelessHART Networks
  • Goals
  • Achitecture
  • Network topology
• General concepts
  • Features, coexistence and diagnostics
  • Network topology, routing and security messages
  • Time Division Multiple Access - TDMA
    • Time Slots
    • Superframes
  • Direct Sequence Frequency Spread Spectrum - DSSS
  • Frequence Hopping Spread Spectrum - FHSS
  • BlackListing
  • Channel Hopping
• Smart wireless network project
  • Site survey
  • Data collection
  • Network ID
  • Join Key
  • Gatweway commissioining
  • Devices commissioning
  • Godd practices
• Smar WirelessHART network components detailing
  • System components
  • Field devices instruments
  • Adapters, power supply and maintenance acess
  • Routers
  • Gateways
  • Network manager
  • Security manager
  • Hosts
• SYSTEM302 architecture applied to Wireless HART protocol
• SYSTEM302 package software installation
  • Configuration Database
  • License levels
  • Network setup communication
  • System operational tools
• Wireless HART configuration aspects
  • Standard and enhanced FF function blocks
  • SYSCON configuration tool
  • Practices with function blocks and Smar DF100 HSE controller
  • Status propagation and fail safe conditions mechanism
  • MODBUS communication
  • SimulationView – SYSTEM302 software simulation tool
  • OPC communication - supervision level
• Client-server communication
• Multi-User system application
• System maintenance aspects
  • Firmware download
  • Devices and components replacement

 Prerequisite
Knowledge in industrial instrumentation and computer (Windows environment)

Program Length
16 hours (2 working days)
