Training in SYSTEM302 Foundation Fieldbus Maintenance

The SYSTEM302 Foundation Fieldbus maintenance training module presents the tools and procedures to set, calibrate and replace general hardware & software components available at Smar SYSTEM302 package.

The participant will be able to

• Understand the Foundation fieldbus technology and benefits
• Know the SYSTEM302 components to Foundation Fieldbus technology support
• Adjust, commit and start FF network applications
• Understand the status propagation & safe limits concepts
• Apply the maintenance procedures and software utilities for SYSTEM302 components

Topics

• Foundation Fieldbus technology and its installation aspects
• SYSTEM302 architecture applied to Foundation Fieldbus technology
• FF network settings & monitoring
  • Procedures for communicating with FF field devices
  • Addressing, commissioning and discharge configuration
  • FF function blocks parameterization and monitoring (RES, TRD, DSP, AI, AO)
• FF redundant applications
• Device description files & EDDL technology
• Network protection and intrinsic safety applicatrions
• SYSTEM302 utilities and maintenance procedures
  • DF63/63 Smar HSE FF Procedures maintenance procedures
  • SYSTEM302 field devices installation, maintenance and calibration
    • Pressure and temperature transmitters
    • Signal converters
    • Valve positioning and position transmitter
    • Concentration/density transmitter
    • H1 remote interfaces
  • Replacing mechanical/electronic sensors and circuit boards
  • Cleaning and preventive maintenance
  • Firmware download
  • Replacing controllers and H1 field devices
• FBView – Fieldbus Analyzer
• AssetView - Online Plant Asset Management System

Pre-requisite
Knowledge of industrial automation and computers (Windows environment)

Program length
32 hours (4 working days)
