Training in SYSTEM302 HSE DF73/95/97 PROFIBUS Controllers

This training module introduces Smar SYTEM302 architecture to PROFIBUS technology focusing the system configuration aspects, I/O variables mapping tools, system communication network environment and operational tools.

The participant will be able to

• Understand PROFIBUS techonology
• Understand SYTEM302 architecture to PROFIBUS technology
• Apply PROFIBUS-PA function blocks configuration
• Understand OPC Communication – supervisory system
• Configure 4-20mA/HART, MODBUS, logic and discrete applications
• Optimize and set PROFIBUS network communication
• Apply system operational tools

Topics

• PROFIBUS technology
  • PROFIBUS DP & PA levels
  • PROFIBUS-DP level description
    • RS-485 Serial and MODBUS communication
    • PROFIBUS-DP network topology
  • PROFIBUS-PA level description
  • IEC-61158-2
  • PROFIBUS-PA network topology
• PROFIBUS installation aspects
  • PROFIBUS DP/PA components and accessories
    • Cabling, power supply and terminators
    • Coupler, Link, Repeaters and Junction Boxes
  • Spur and trunks length recommendations
  • Network topology
  • Network protection aspects
• SYSTEM302 architecture applied to PROFIBUS technology
  • SYSTEM302 Software Installation
  • Database Configuration
  • License Utility
  • Network Communication Settings
  • System operational tools
• PROFIBUS cyclic configuration
  • 4-20mA/HART, logic and discrete configuration
  • Flexible function block (FFB) applications
  • PROFIBUS-PA function blocks and I/O mapping tools
  • DF73/95/97 HSE Processors practices
  • Advanced I/O mapping: Sensors, Start/Stop Motors, Frequency Inverters, ON/OFF Valves, etc
  • SYSCON, LOGICVIEW & NETCONF software applications
  • MODBUS and other industrial automation protocols integration
  • FDT/DTM and EDDL technologies integration
  • OPC communication – supervisory system
  • DF73/95/97 in redundant architectures
    • Media, ports, power supply, I/O cards and master availability
  • SimulationView – SYSTEM302 software simulation tool
• Multi-User system application
• System maintenance aspects
  • Firmware Download
  • Devices and components replacement

Pre-requisite
Knowledge of industrial automation, programmable controllers and computers (Windows environment)

Program length
32 hours (4 working days)
